Single Acting Low Height Pad Cylinders
The HPS pad cylinder range offers the best capacity, closed height and stroke length combination, spring assisted return cylinders in the industry. Ideally suited for applications where a low closed height and maximum possible stroke is of prime importance.
These highly versatile cylinders are extensively used for maintenance, structural weld positioning, rigging, flange separating and many other applications.
- Single acting, spring assisted return
- Nitrocarburised piston rod
- Low friction bearing surfaces
- Anti-extrusion seals
- Capacities from 4.5 to 147 tonnes
- Stroke lengths from 6 to 16mm
- Working pressure 700 Bar
