Superlift Modular Beams
The SuperLift system is a wide range of modular spreader system components, offering a variety of different spans for all your lifting needs.
Offer an extensive range of spreader beams for sale or to hire from 3 tonne to 110 tonnes.
- The Flexibility of the Superlift beam configuration enables our spreader beam configuration to be reused, offering a cost effective solution
- The hire of our Superlift beam comes complete with top and bottom Shackles.
- Wires are available upon request, please talk to our sales to discuss your requirements.
Superlift 6
- Minimum Beam Length 500mm
- Maximum Beam Length 4 meters
- Max. Load Capacity 8 tonnes capacity at 2 meters and 6 tonnes capacity at 3 meter span
Superlift10
- Minimum Beam Length 500mm
- Maximum Beam Length 10 meters
- Max. Load Capacity 16 tonnes capacity at 5.5 meters and 10 tonnes capacity at 7 meter span
- Minimum Beam Length 500mm
- Maximum Beam Length 12 meters
- Max. Load Capacity 24 tonnes capacity at 5.5 meters and 20 tonnes capacity at 6 meter span
- Minimum Beam Length 1000mm
- Maximum Beam Length 16 meters
- Max. Load Capacity 50 tonnes capacity at 6 meters and 40 tonnes capacity at 8 meter span
- Minimum Beam Length 1000mm
- Maximum Beam Length 20 meters
- Max. Load Capacity 80 tonnes capacity at 11 meters and 50 tonnes capacity at 15 meter span
- Minimum Beam Length 1000mm
- Maximum Beam Length 22 meters
- Max. Load Capacity 170 tonnes capacity at 8.5 meters and 110 tonnes capacity at 12 meter span
Contact us here for more information or call our friendly sales team on +44 (0)1472 358 310
